1 To 4 100rpm Plastic Strap Making Machine PP PET Strap Extrusion Line

Price :	$40,000.00/sets >=1 sets	Packaging Details :	Standard export packaging for PET Strap production line
Supply Ability :	50 Set/Sets per Month

Place of Origin:	Jiangsu, China	Brand Name:	MOOGE
Certification:	CE SGS

Detail Information
Application:	Plastic Band/strap	Plastic Processed:	PET
Condition:	New	Screw Design:	Single-screw
Screw Material:	38CrMoAlA	Screw Diameter (mm):	90 Mm
Screw L/D Ratio:	33:1	Screw Speed (rpm):	100 Rpm
Showroom Location:	Egypt, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri	Voltage:	380/220/440
Dimension(LWH):	According To Model	Weight:	According To Model
Warranty:	1 Year	Key Selling Points:	High Productivity
Applicable Industries:	Manufacturing Plant	Marketing Type:	New Product 2020
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Bearing, Motor, Gear, PLC, Engine, Gearbox
Raw Material:	Recycle Pet Flakes Or Virgin Material	PLC:	Siemens
Die Head Extruder:	Single Or Double	Capacity:	50-250kg/h
Strap Width Size:	9-19	Strap Thickness Size:	0.5-1.5mm
Extruder Screw:	38crmoal	After-sales Service Provided:	Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
After Warranty Service:	Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service	Local Service Location:	Egypt, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Japan, Malaysia, Australia, Morocco, Kenya, Argentina, South Korea, Chile,
Port:	Shanghai
Highlight:	1 to 4 Plastic Strap Making Machine , 100rpm Plastic Strap Making Machine , PP pet strap extrusion line

Product Description

1 To 4 PP Strap Plastic Strapping Extruder Production Line PET Strap Making Machine

Product Description

pet strap is made of polyethylene terephthalate as the main raw material, it is currently used as a substitute for steel belt in the world. It can packing paper box,brick,wood pallet,cloth, glass,plastic pipe,other plastic product etc.Wide using in the life

Advance for pet strap :

1. Tensile: PET plastic strip is a kind of packaging material with good tensile strength and excellent welding performance.

2. The elongation is small: the elongation is only one-sixth of that of the polypropylene (PP) belt, and the tension can be maintained a long time.

3 strong temperature resistance: melting point of 260 degrees, superior weather resistance, between -50 ° C -120° C, maintaining good stability.

4.Compare with steel strap,it have obvious economic benefits for customer

Product Paramenters

Model	Capacity (kg/h )	Strap size (mm)	Installed Power (KW)	Manpower	Machine size (LWH m)
SJ65/33 Single strap	50~60	9~19	85	1~2	3545
SJ75/33 Single strap	80~100	9~19	100	1~2	3846
SJ75/33 Double strap	80~120	9~19	110	1~2	4046
SJ90/33 Double strap	150~200	9~19	150	1~2	4557
SJ120/33 Double strap	200~300	9~19	220	1~2	4557
