Waste Plastic Bottle Crusher for Recycling Use

Contact Now

Waste Plastic Bottle Crusher for Recycling Use

Minimum Order Quantity :	1	Price :	$7,900.00/set
Packaging Details :	as customer requirement	Delivery Time :	55-65 DAYS
Supply Ability :	20 Set/Sets per Month

Place of Origin:	Jiangsu, China	Brand Name:	MOOGE TECH
Certification:	CE ISO	Model Number:	SM-800

Detail Information
Condition:	New	Plastic Type:	PET
Machine Type:	Plastic Crusher	Max.Production Capacity (kg/h):	2000
Production Capacity (kg/h):	100 - 2000 Kg/h	Use:	Bottle Crusher
Voltage:	380V 50HZ	Dimension(LWH):	11058501920mm
Power (kW):	22	Weight (T):	2
Warranty:	1 Year, 12 Months	Applicable Industries:	Manufacturing Plant
Key Selling Points:	Automatic	Showroom Location:	Egypt
Marketing Type:	Other	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	1 Year
Core Components:	Motor	Color:	Customers' Demand
Application:	Recycle Waste Plastic	Blades Material:	SKD-11
Rotor Blade:	8-12	Fixed Blade:	4
Screen(mm):	14	Capacity:	300-2000kg/hr
Motor:	TaiWan GuanHua	RPM:	580
After-sales Service Provided:	Online Support	After Warranty Service:	Online Support
Local Service Location:	Egypt	Port:	Shanghai

Product Description

MOOGE TECH GROUP is a focus on machinery manufacturing and research and development of enterprises, The company takes"honesty,innovation, quality, service’ as the core value, and is committed to providing customers with efficient, high-quality machinery and equipment and services.

Product Overview

This Machine Can Be Used for the PET bottle,Plastic Bottle,buckets,hollow containers,and so on plastics;its with special structure design,will have more capacity with less power consumption.

Product Paramenters

We have 300-3000 kg/h SM-Series Plastic Bottles Crushing Machine

Model	Capacity	Power	Screen	Rotor Blade	Fixed Blade
SM-600-45	300KG/H	45	14MM	8	4
SM-800-55	500KG.H	55	14MM	8	4
SM-1000-75	800-1000KG/H	75	14MM	8	4
SM-1200-90	1500-2000KG/H	90	14MM	12	6
SM-1500-110	2000-3000KG/H	110	14MM	12	6

Product Description

SM-Series Crusher Machine

Function: Crushing the material into small size

Bearing house is outside of the crusher chamber so no dirty goes inside for longer use.

Detail Specification

SM-Series Crusher Machine

1-With heavy duty pulley easier for machine working 2-Use the big roller bearing ensure its long time use 3-Bearing house is outside of the crusher 4-chamber so no dirty goes inside for longer use Frame made by solid square tube steel 5-Machine up chamber is higher and covered by belt no flakes pop out

The Rotor Shaft

With strong rotor made and shaft Rotor diameter: 650mm Shaft made by 45# steel with quenching treatment Chamber made by solid steel 40mm thickness by processing use rubber seal between water leaking proof Chamber opened by screw motor

The Crusher Screen

The crusher screen screens and grades the materials through its holes. The size of the holes determines the fineness of the materials.

Motor

With strong rotor made and shaft.Shaft made by 45#steel with quenching treatment

Fixed Blade

The blades more wider can sharpening 20-25 times, it will save the blade cost. Mateial: 9Crsi/SKD-11/D2.

After Crushing
